A1SY80 Digital Output Module

Part Name

Digital Output Module

Model

A1SY80

System Adaptation

Compatible with MELSEC-A/AnS/QnAS series CPUs (such as A2ASCPU, Q02CPU)

Replacement model

QY80 / QY81P

Specifications

Points: 16 points (transistor output)

Type: Source, Common terminal connected **+24V**

Rated voltage: DC12/24V (tolerance 10.2～30V)

Current per point: 0.8A (resistive load)

Public terminal: 8 points / 1 group, total of 2 groups; maximum 3.2A per group

Surge current: ≤8A (within 10ms)

Leakage current (OFF): ≤0.1mA

On-state voltage drop: ≤DC1.5V
